Redis 事件的实现 · Analyze

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

#ifdef HAVE_EVPORT
#include "ae_evport.c"
#else
    #ifdef HAVE_EPOLL
    #include "ae_epoll.c"
    #else
        #ifdef HAVE_KQUEUE
        #include "ae_kqueue.c"
        #else
        #include "ae_select.c"
        #endif
    #endif
#endif

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21

static int aeApiCreate(aeEventLoop *eventLoop) {
    aeApiState *state = zmalloc(sizeof(aeApiState));

    if (!state) return -1;
    // 初始化事件槽空间
    state->events = zmalloc(sizeof(struct epoll_event)*eventLoop->setsize);
    if (!state->events) {
        zfree(state);
        return -1;
    }
    // 创建 epoll 实例
    state->epfd = epoll_create(1024); /* 1024 is just a hint for the kernel */
    if (state->epfd == -1) {
        zfree(state->events);
        zfree(state);
        return -1;
    }
    // 赋值给 eventLoop
    eventLoop->apidata = state;
    return 0;
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

static int aeApiAddEvent(aeEventLoop *eventLoop, int fd, int mask) {
    aeApiState *state = eventLoop->apidata;
    struct epoll_event ee = {0}; /* avoid valgrind warning */
    int op = eventLoop->events[fd].mask == AE_NONE ?
            EPOLL_CTL_ADD : EPOLL_CTL_MOD;

    ee.events = 0;
    mask |= eventLoop->events[fd].mask; /* Merge old events */
    if (mask & AE_READABLE) ee.events |= EPOLLIN;
    if (mask & AE_WRITABLE) ee.events |= EPOLLOUT;
    ee.data.fd = fd;
    if (epoll_ctl(state->epfd,op,fd,&ee) == -1) return -1;
    return 0;
}
static void aeApiDelEvent(aeEventLoop *eventLoop, int fd, int delmask) {
    aeApiState *state = eventLoop->apidata;
    struct epoll_event ee = {0}; /* avoid valgrind warning */
    int mask = eventLoop->events[fd].mask & (~delmask);

    ee.events = 0;
    if (mask & AE_READABLE) ee.events |= EPOLLIN;
    if (mask & AE_WRITABLE) ee.events |= EPOLLOUT;
    ee.data.fd = fd;
    if (mask != AE_NONE) {
        epoll_ctl(state->epfd,EPOLL_CTL_MOD,fd,&ee);
    } else {
        epoll_ctl(state->epfd,EPOLL_CTL_DEL,fd,&ee);
    }
}

1
2
3
4
5
6
7
8

static int aeApiPoll(aeEventLoop *eventLoop, struct timeval *tvp) {
    aeApiState *state = eventLoop->apidata;
    int retval, numevents = 0;

    retval = epoll_wait(state->epfd,state->events,eventLoop->setsize,
            tvp ? (tvp->tv_sec*1000 + tvp->tv_usec/1000) : -1);
	...
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

            if (!invert && fe->mask & mask & AE_READABLE) {
                fe->rfileProc(eventLoop,fd,fe->clientData,mask);
                fired++;
            }
            if (fe->mask & mask & AE_WRITABLE) {
                if (!fired || fe->wfileProc != fe->rfileProc) {
                    fe->wfileProc(eventLoop,fd,fe->clientData,mask);
                    fired++;
                }
            }

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

typedef struct aeFileEvent {
    // 监听事件类型掩码
    int mask; /* one of AE_(READABLE|WRITABLE|BARRIER) */
    // 读事件处理器
    aeFileProc *rfileProc;
    // 写事件处理器
    aeFileProc *wfileProc;
    // 多路复用库的私有数据
    void *clientData;
} aeFileEvent;

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

int aeCreateFileEvent(aeEventLoop *eventLoop, int fd, int mask,
        aeFileProc *proc, void *clientData)
{
    if (fd >= eventLoop->setsize) {
        errno = ERANGE;
        return AE_ERR;
    }
    aeFileEvent *fe = &eventLoop->events[fd];

    // 将该事件注册到 I/O 多路复用程序中
    if (aeApiAddEvent(eventLoop, fd, mask) == -1)
        return AE_ERR;
    fe->mask |= mask;
    if (mask & AE_READABLE) fe->rfileProc = proc;
    if (mask & AE_WRITABLE) fe->wfileProc = proc;
    fe->clientData = clientData;
    if (fd > eventLoop->maxfd)
        eventLoop->maxfd = fd;
    return AE_OK;
}

// 注册同步事件
aeCreateFileEvent(server.el,fd,AE_READABLE|AE_WRITABLE,syncWithMaster,NULL);

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

typedef struct aeTimeEvent {
    // 时间事件的唯一标识符
    long long id; /* time event identifier. */
    // 事件的到达时间
    long when_sec; /* seconds */
    long when_ms; /* milliseconds */
    // 事件处理函数
    aeTimeProc *timeProc;
    // 事件释放函数
    aeEventFinalizerProc *finalizerProc;
    // 多路复用库的私有数据
    void *clientData;
    // 指向上/下个时间事件结构，形成链表
    struct aeTimeEvent *prev;
    struct aeTimeEvent *next;
} aeTimeEvent;

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19

        aeGetTime(&now_sec, &now_ms);
        // 如果当前时间等于或等于事件的执行时间，那么说明事件已到达，执行这个事件
        if (now_sec > te->when_sec ||
            (now_sec == te->when_sec && now_ms >= te->when_ms))
        {
            int retval;
            id = te->id;
            // 执行事件处理器，并获取返回值
            retval = te->timeProc(eventLoop, id, te->clientData);
            processed++;
            // 是否需要循环执行这个事件时间
            if (retval != AE_NOMORE) {
                // 需要， retval 毫秒之后继续执行这个时间事件
                aeAddMillisecondsToNow(retval,&te->when_sec,&te->when_ms);
            } else {
                // 不需要，将这个事件删除
                te->id = AE_DELETED_EVENT_ID;
            }
        }

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

int main(int argc, char **argv) {
    ...
    aeMain(server.el);
}
void aeMain(aeEventLoop *eventLoop) {
    eventLoop->stop = 0;
    while (!eventLoop->stop) {
        if (eventLoop->beforesleep != NULL)
            eventLoop->beforesleep(eventLoop);
        aeProcessEvents(eventLoop, AE_ALL_EVENTS|AE_CALL_AFTER_SLEEP);
    }
}
